Description

The moisture content tester features a variety of practical functions and reliable performance. It is designed for scenarios requiring moisture content detection, providing users with a convenient and precise solution for moisture analysis.

Application

11 Function Settings

Heating Mode Setting	Stop Mode Setting	Heating Temp. Setting
Heating Time Setting	Baud Rate Setting	Language (CN/EN) Setting
Date & Time Setting	Data Storage Setting	Factory Reset
Instrument Calibration	Empty Pan Preheating

Features

Full-color touch screen
Real-time testing curve
Standard / Fast/ Softmodes
Automatic/Manual/Timed stop mode
Silent rapid cooling fan
Adaptive micro-voltage adjustment
Test frequency selection
Clock function
History record query

Specification

Model	MCA110-T10E	MCA110-T5E	MCA110-T1E
Max. Capacity	110g
Readability	0.01g	0.005g	0.001g
Sensor	Load cell
Pan Size	φ100mm
Display	5-inch full-color touch screen
Operating Temperature	15℃~30℃
Heat Source	Halogen lamp
Temp. Sensor	PT100
Temp. Range	40°C~160°C (1°C step)
Time Setting	1~99min (10s step)
Moisture Range	0.00%~100.00%
Moisture Readability	0.10%	0.05%	0.01%
Solid Content Range	100.00%~0.00%
Solid Content Readability	0.10%	0.05%	0.01%
Data Storage	20 Groups
Real-time Curve	Real-time dynamic curve
Testing Space	30mm
Electricity	220V, 50Hz / 110V, 60Hz
External Dimensions	340215170mm
Package Dimensions	415310255mm
N.W./G.W.	4.0kg/3.5kg
